Specs
Quick Specs
1U rack server
Processor | Max: 64 Cores2x 2nd or 3rd Gen AMD EPYC
Memory | Max: 2TB RDIMM | 4TB LRDIMM32 DDR4 RDIMM/LRDIMM 3200Mhz
Storage | Max: N/A4x 3.5" SAS/NL-SAS/SATA (HDD/SSD)
Rear Drives | Max: N/A2 SFF SAS/SATA (HDD/SSD) NVMe (10 Bay Only)
RAID Controller: S150 (SW RAID)
HBA345, H345, H745, H840, 12G SAS HBA, H755, H755N
BOSS
BOSS-S2
IDSDM
OCP x16 Mezz 3.0 + 2 x 1GE LOM
Remote Management:iDRAC9 with Lifecycle Controller
PCIe Slots:3 x Gen4 slots (x16) at 16GT/s
GPU:Up to 3 Single-Wide GPU
Ideal for:
- High-Performance Computing (HPC)
- Virtual Desktop Interface (VDI)
- Virtualization
The Dell EMC PowerEdge R6525 Rack Server is a highly configurable, dual-socket 1U rack server that delivers outstanding balanced performance and innovations for dense compute environments to address traditional and emerging workloads and applications.
The new Dell EMC PowerEdge R6525 is a highly configurable, dual-socket 1U rack server that delivers outstanding balanced performance and innovation for dense compute environments. It’s ideal for traditional and emerging workloads and applications. High-level features include:
- 64 processing cores and faster data transfer speeds with PCIe Gen 4
- Up to 3200MT/s memory speed to reduce latency and deliver faster response
- Multi GPU support to accelerate end user VDI performance
- Highest core count PE 1U server with cryptographic isolation between hypervisor and VMs
The Dell EMC OpenManage™ systems management portfolio delivers an efficient and comprehensive solution for PowerEdge servers through tailored, automated, and repeatable processes.
- Automate server life cycle management with scripting via the iDRAC Restful API with Redfish conformance.
- Simplify and centralize one-to-many management with the OpenManage Enterprise console.
- Utilize the OpenManage Mobile app and PowerEdge Quick Sync 2 to easily manage servers using a phone or tablet.
- Resolve issues with up to 72% less IT effort using automated proactive and predictive technology from ProSupport Plus and SupportAssist.**
Fortify your data center with integrated security
Every PowerEdge server is designed with a cyber-resilient architecture, integrating security deeply into every phase in the lifecycle, from design to retirement.
- Enhance security with platform enablement of AMD Secure Memory Encryption (SME) and Secure Encrypted Virtualization (SEV).
- Operate your workloads on a secure platform anchored by cryptographically trusted booting and silicon root of trust.
- Maintain server firmware safety with digitally signed firmware packages.
- Detect and remediate unauthorized or malicious change with drift detection
Looking to Customize?
Need assistance with customization? Our sales experts are here to help you.
Start Customizing Today!
Base Standard Capabilities
| Feature | Technical Specification | |
|---|---|---|
| Processor | Two 2nd or 3rd Generation AMD EPYCTM Processors with up to 64 cores per processor | |
| Memory | Up to 32 x DDR4 up to 3200 MT/S Maximum RAM: RDIMM 2 TB LRDIMM 4TB Max | |
| Storage controllers |
| |
| Drive bays | Front bays:
| |
| Power supplies |
| |
| Fans | Hot plug Fans | |
| Dimensions | Height: 42.8mm (1.7”) Width: 434.0mm (17.1”) Depth: 736.54mm (29”) Weight: 21.8kg (48.06lbs) | |
| Form Factor | 1U rack server | |
| Embedded mgmt |
| |
| Bezel | Optional LCD bezel or security bezel | |
| OpenManage™ Software | Consoles
| |
| Integrations & Connections | OpenManage Integrations
| OpenManage Connections
|
| Security |
| |
| Embedded NIC | 2 x 1 GbE LOM ports | |
| Networking Options (NOC) | OCP x16 Mezz 3.0 + 2 x 1GE LOM | |
| GPU Options | Up 2 Single-Wide GPU | |
| Ports | Front Ports:
| Rear Ports
|
| PCIe | 3 x Gen4 slots (x16) at 16GT/s | |
| Operating System and Hypervisors |
| |
Spec Sheet 4
| Feature | PowerEdge R6525 | PowerEdge R6415 |
|---|---|---|
| Processor | Two AMD® EPYC™ Generation 2 or Generation 3 processors | One AMD Naples® socket SP3 compatible processor |
| CPU Interconnect | Interchip global memory interconnect (xGMI) | N/A |
| Memory | 32x DDR4 RDIMM, LRDIMM, 3DS | 16x DDR4 RDIMM, LRDIMM |
| Storage Drives | 3.5-inch, 2.5-inch: 12G SAS, 6G SATA hard drive | 3.5-inch, 2.5-inch: 12G SAS, 6G SATA HDD/SSD |
| Storage Controllers | H755N, H840, H745, HBA345, H345,
HBA355, HBA355E SW RAID: S150 |
Mini PERC: HBA330, H330, H730P,
H740P
SW RAID: S140 |
| PCIe SSD | Up to 10+2 PCIe SSD | Up to 10x PCIe SSD |
| PCIe Slots | Up to 3 (PCIe 4.0 x16) | Up to 2 (PCIe 3.0 x16) |
| LOM | No LOM riser supported on R6525. | LOM riser options:
● 2 x 1 Gb ● 2 x 10 Gb Base-T ● 2 x 10 Gb SFP+ |
| OCP | OCP 3.0 SCFF (Small Card Form Factor) | OCP 2.0 Type 1: (Connector A) |
| USB Ports | Front: 1x USB 2.0, 1x iDRAC USB
(Micro-AB USB)
Rear: 1x USB 3.0, 1x USB 2.0 |
Front: 1x USB2.0, 1x iDRAC USB (Micro
USB)
Rear: 2x USB3.1_Gen1 |
| Rack Height | 1U | 1U |
| Power Supplies | AC/HVDC (Platinum) 800 W, 1400 W , Mixed Mode AC/HVDC (Platinum) 800 W, 1400 W, (Titanium) 1100 W Mixed Mode AC/HVDC, (-48 V) 1100 W DC PSU , (Titanium) 700 W, 1800 W Mixed Mode AC | AC (gold) 450 W cabled AC (Platinum) 550 W |
| System Management | LC 3.x, OpenManage, QuickSync2.0, OMPC3, Digital License Key, iDRAC Direct (dedicated micro-USB port), Easy Restore | LC 3.x, OpenManage, QuickSync2.0, OMPC3, Digital License Key, iDRAC Direct (dedicated micro-USB port), Easy Restore, vFlash |
| Internal GPU | ● 2x 75 W (SW/FH)
● 1x 75 W (SW/FH) ● 3x 75 W (SW/LP) |
N/A |
| Availability | Hot-plug drives, Hot-plug Redundant Power supplies, BOSS, IDSDM. | Hot-plug drives, Hot-plug Redundant Power supplies, BOSS, IDSDM. |
