Specs
Quick Specs
1U rack server
Processor | Max: 20 Cores2x Intel Gen 1 | 2 Xeon Scalable
Memory | Max: 1TB12 DDR4 RDIMM/LRDIMM 2666Mhz
Storage | Max: 64TB or 76.8TB8 x 2.5 inch SAS/SATA
RAID Controller:S140 (SW RAID)
H330, H350, H730P, H740P, H750
HBA355e, H840, 12 Gbps Ext SAS HBA
HBA330, HBA350i
2x 1GbE LOM
(Optional LOM Riser) 2 x 1GbE or 2x 10GbE SFP+ or 2 x 10GbE BaseT
BOSS-S1
Internal dual SD module (IDSDM)
iDRAC9 with Lifecycle Controller
PCIe Slots:2x PCIe Gen 3 slots plus a dedicated PERC and LOM slot
GPU:None
Ideal for:
- High-Performance Computing (HPC)
- Web Tech
The Dell EMC PowerEdge R440 delivers the perfect combination of performance and density for HPC and web-tech deployments with a feature set right-sized for scale-out infrastructure environments.
Deliver performance at scale with the Dell EMC PowerEdge portfolio
Modern compute platforms from Dell EMC easily scale and leverage key technologies to maximize application performance. The Dell EMC PowerEdge R440 is built on a scalable architecture that provides the choice and flexibility to optimize performance and density.
- Scale compute resources with 2nd Generation Intel Xeon Scalable processors, and tailor performance based on your unique workload requirements.
- Flexible storage with up to 10 x 2.5 SAS/SATA/SSD with up to 4 NVMe PCIe SSD’s or 4 x 3.5.
- Free up storage with boot optimized M.2 SSDs.
The Dell EMC OpenManage portfolio helps deliver peak efficiency for PowerEdge servers, delivering intelligent, automated management of routine tasks. Combined with unique agent-free management capabilities, the Dell EMC PowerEdge R440 is simply managed, freeing up time for high profile projects.
- Simplify management of your servers with OpenManage Essentials, a 1:many console that automates all phases of lifecycle management: deployment, updates, monitoring, and maintenance.
- Use Quick Sync 2, a wireless module, and the OpenManage Mobile app for at-server management, to configure or troubleshoot in the data center, and to receive alerts when you’re on the go.
Rely on PowerEdge with built-in security
Every PowerEdge server is made with a cyber-resilient architecture, building security into all parts of a server’s life cycle. The R440 uses these new security features so you can reliably and securely deliver the right data to where your customers are, no matter where they are. Dell EMC consider each part of system security, from design to end of life, to ensure trust and deliver worry-free, secure systems.
- Rely on a secure supply chain that protects servers from factory to the data center.
- Maintain data safety with cryptographically signed firmware packages and Secure Boot.
- Prevent unauthorized or malicious change with Server Lockdown.
- Wipe all data from storage media including hard drives, SSDs and system memory quickly and securely with System Erase.
Performance in a density-optimized 1U, 2-socket rack server
Experience an outstanding balance of performance and density for scale-out computing. The Dell EMC PowerEdge R440 brings you value in a small form factor. Benefit from platform flexibility and maximize performance with dual 2nd Generation Intel Xeon Scalable processors, up to 16 DIMMs and scalable storage that lets you mix SSDs and NVMe PCIe SSDs. Embedded diagnostics and SupportAssist help the Dell EMC PowerEdge R440 to deliver maximum uptime in a worry-free environment.
Deliver performance at scale with the PowerEdge portfolio
Modern compute platforms from Dell EMC are designed to scale easily and use technologies that maximize application performance. The PowerEdge R440 rack server provides choice and flexibility that lets you optimize performance and density.
- Scale compute resources with 2nd Generation Intel Xeon Scalable processors and tailor performance based on your unique workload requirements.
- Gain storage flexibility with up to 10 x 2.5" SAS/SATA/SSD with up to 4 NVMe PCIe SSDs, or 4 x 3.5" disks.
- Free up storage with boot-optimized M.2 SSDs.
Looking to Customize?
Need assistance with customization? Our sales experts are here to help you.
Start Customizing Today!
Base Standard Capabilities
| Feature | Technical Specification | |
|---|---|---|
| Processor | Up to two 2nd Generation Intel® Xeon® Scalable processors, up to 24 cores per processor | |
| Memory | 16 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2666MT/s, 1TB max | |
| Storage controllers |
| |
| Internal boot |
| |
| Drive bays | Front bays:
| |
| Power supplies |
| |
| Fans | Up to six cabled fans | |
| Dimensions | Form factor: Rack (1U) Height: 42.8mm (1.68”) Width*: 434mm (17.08”) Depth*: 714.62mm (28.13”) Weight: 17.6kg (38.9lbs.) | |
| Bezel | Optional LCD or security bezel | |
| Embedded management |
| |
| Consoles & Mobile | OpenManage Enterprise OpenManage Essentials OpenManage Power Manager OpenManage Mobile | |
| Integrations | OpenManage integrations: Microsoft® System Center, VMware® vCenter™, BMC Truesight, Red Hat® Ansible® Modules | |
| Connections | OpenManage connections: Nagios® & Nagios® XI, IBM Tivoli Netcool/OMNIbus, Micro Focus Operations Manager | |
| Tools |
|
|
| Security |
|
|
| I/O & Ports | Networking Options:
| Up to 2 x PCIe Gen 3 slots all x16 |
| Supported operating systems |
|
|
Spec Sheet 4
| Feature | PowerEdge R440 | PowerEdge R430 |
|---|---|---|
| Processor | 2nd Generation Intel Xeon Scalable Processor Family | Intel Xeon E5-2600 v3 or E5-2600 v4 processor |
| Chipset | Intel C620 | Intel C610 |
| Memory | 16x DDR4 RDIMM, LRDIMM | 12x DDR4 RDIMM, LR-DIMM |
| Drive bays | 3.5 inch, 2.5 inch - 12Gb SAS, 6Gb SATA and PCIe Storage (NVME) | 3.5 inch, 2.5 inch - 12Gb SAS, 6Gb SATA |
| PCIe Slots | 2x PCIe Gen3 (x16/x16) | 2x PCIe Gen3 (x16/x8) |
| RAID Controller | PERC 9/10/11 | Mini-PERC 9 |
| RAID Controller | ● 10 x 2.5 inch SAS/SATA/NVMe
● 8 x 2.5 inch SAS/SATA ● 4 x 3.5 inch SAS/SATA |
● 10 x 2.5 inch SAS/SATA
● 8 x 2.5 inch SAS/SATA ● 4 x 3.5 or 2.5 inch SAS/SATA |
| Embedded NIC | 2x 1Gb LOM and optional LAN on riser
card:
● 2x 1GbE ● 2x 10GbE ● 2x 10GbE SFP+ |
4 x 1Gb LOM |
| Power Supplies | 450 W AC Cabled PSU, 550 W AC PSU | 450 W AC Cabled PSU, 550 W AC PSU |
| Remote Management | iDRAC9 | iDRAC8 |
| TPM | TPM 2.0 China, TPM1.2, TPM2.0 | TPM China, TPM1.2, TPM2.0 |
| Rear USB 3.0 port | Two rear ports | One rear port |
| iDRAC Direct front port | Micro USB | USB type A |
| Cooling Fan | Up to 6 fan support | Up to 6 fan support |
| IDSDM Module | Internal Dual SD Module (IDSDM) and vFlash | Internal Dual SD Module (IDSDM) |
| BOSS Module | M.2 SATA interface | None |
