Base Specs
| Feature | MD3060e |
|---|---|
| Drives | 60 |
| Drive type | Mix and match 3.5” and 2.5” SAS, NL-SAS, SSD, SED |
| 3.5" drive capacity | NL-SAS 7.2K RPM: 500GB, 1TB, 2TB, 3TB, 4TB, 6TB, 8TB, 10TB SSD: 200GB, 400GB, 800GB (WI); 400GB, 800GB, 1.6TB (MU); 800GB, 1.6TB (RI) (available with 3.5” HDD carriers) |
| 2.5" drive capacity | SAS 15K RPM: 146GB, 300GB, 600GB SAS 10K RPM: 146GB, 300GB, 600GB, 900GB, 1.2TB NL-SAS 7.2K RPM: 500GB3, 1TB, 2TB SSD: 200GB, 400GB, 800GB (WI); 400GB, 800GB, 1.6TB (MU); 800GB, 1.6TB (RI) 3.5” 10K and 15K HDDs are not supported on the dense model |
| Expansion capabilities | Up to 4 dense enclosures behind a single server |
| Controllers | Dual Enclosure Management Modules (EMMs) |
| Maximum HA host | 2 |
| Form factor | 4U rack enclosure |
| Management software | Server controller dependent |
| Server support | Dell PowerEdge R630, R730 and R730xd servers |
| OS support | Microsoft Windows Server 2012 R2, Red Hat Enterprise Linux 6.5, Ubuntu 12.04 LTS, and Debian 7.4 |
| Physical dimensions (height x width x depth) | 177.8 mm (7.0”) x 482.6 mm (19.0”) x 825.5 mm (32.5”) |
| Maximum weight | 105.20 kg (232.0 lb) |
| Environment | |
| Power | AC: 1755W |
| Heat dissipation (max) | 5988 BTU/hr |
| Voltage | 220V AC, auto ranging |
| Frequency range | 50/60Hz |
| Temperature | Operating: 10° to 35°C (50° to 95°F) with a maximum temperature gradation of 10°C per hour |
| Relative humidity | Operating: 10% to 80% (non-condensing) with a maximum humidity gradation of 10% per hour |
| Altitude | Operating: -30.5 m to 3000 m (-100 ft to 9,840 ft) Note: For altitudes above 2950 ft, the maximum operating temperature is derated 1.8°F/1000 ft. |
