Dell PowerEdge R930 Rack Server Chassis (16x2.5" + 8x2.5" NVMe)

PER930-24x2.5 | Refurbished Dell PowerEdge R930 Rack Server Chassis (24x2.5")

SKU: DPE-R930-24x2.5+NVMe-Chassis

Dell PowerEdge R930 Rack Server Chassis (16x2.5" + 8x2.5" NVMe)

Name: Dell PowerEdge R930 Rack Server Chassis (16x2.5" + 8x2.5" NVMe)
Brand: Dell
SKU: DPE-R930-24x2.5+NVMe-Chassis
Price: 1500.0 USD
Availability: InStock

Dell

| Chassis

.price-ui--loading { display: block !important; opacity: 1 !important; }

$1,500.00

Thanks for the request. We'll get back to you with in 24 hours.

Quick Specs

Form Factor:

4U rack server

Processor Max: N/A

2x or 4x Intel E7-4800 v4 or E7-8800 v4

Memory Max: 12TB

96 DDR4 RDIMM, LRDIMM 2400Mhz

Storage Max: N/A

24 SFF SAS/NL-SAS/SATA (HDD/SSD)
Up to 8 NVMe supported

Rear Storage:

None

Boot Options:

USB
IDSDM (Virtualized Platforms only)

PCIe Slots:

Up to 10 PCIe slots
8 PCIe 3.0
+ 1 RAID slot
+ 1 NDC slot

Remote management:

iDRAC8 Express with Lifecycle Controller

LOM / rNDC:

4 x 1GbE LOM

RAID controllers: (Supports Dual Controllers)

PERC H330, H730P, H830, 12Gbps SAS HBA

Other Versions

Ideal for:

Database
High-Performance Computing (HPC)
Retail Servers

Looking to Customize?

Need assistance with customization? Our sales experts are here to help you.

Start Customizing Today!

Base Standard Capabilities

Features	PowerEdge R930 Technical specification
Form factor	4U
Dimensions	H: 86.8 mm (3.417 in), W: 482.4 mm (18.99 in), D: 811.06 mm (31.93 in) with PSU and bezel D: 776.46 mm (30.59 in) PSU without bezel
Processor	Intel Xeon E7-8800 v4 and E7-4800 v4 processors
Processor sockets	4
Internal interconnect	Intel QuickPath Interconnect (QPI)
Cache	Up to 60MB
Chipset	Intel C602J
Memory	Up to 12TB (96 DIMM slots): 8GB/16GB/32GB/64GB/128GB DDR4, RDIMM, LRDIMM up 2400MT/s
I/O slots	Up to 10 PCIe 3.0 slots + 1 RAID slot + 1 NDC slot
RAID controllers	Internal controllers: PERC H330, PERC H730P External HBAs (RAID): PERC H830 External HBAs (non-RAID): 12Gbps SAS HBA
Hard drives	2.5" SATA/SAS SSD, SAS HDD (15K, 10K), nearline SAS HDD (7.2K) 2.5" PCIe SSDs: Dell PowerEdge NVMe Express Flash PCIe SSD
Drive bays	Up to 24 2.5" hot-plug 12Gb/6Gb SAS HDD or SAS/SATA SSD Up to 8 front-accessible Express Flash NVMe PCIe SSD (PCIe 3.0)
Embedded NIC	Refer to Dell.com/poweredge for the supported NICs
Remote management	iDRAC8 with Lifecycle Controller iDRAC8 Express (default) iDRAC8 Enterprise (upgrade option) 8GB or 16GB vFlash media (upgrade options)
Systems management	IPMI 2.0 compliant Dell OpenManage Essentials Dell OpenManage Mobile Dell OpenManage Power Center Dell OpenManage Integrations: Dell OpenManage Integration Suite for Microsoft System Center Dell OpenManage Integration for VMware vCenter Dell OpenManage Connections: HP Operations Manager, IBM Tivoli Netcool , and CA Network and Systems Management Dell OpenManage Plug-in for Oracle Database Manager
Power supplies	Hot-plug redundant PSUs: 750W AC, 1100W AC
Availability	Hot-plug hard drives, hot-plug redundant power, hot-plug redundant fans, ECC memory, internal dual SD module
Operating systems	Microsoft Windows Server 2012 R2 Microsoft Windows Server 2012 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux VMware vSphere ESXi For more information on specific versions and additions, visit Dell.com/OSsupport.
OEM-ready version available	From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you. For more information, visit Dell.com/OEM.
