Dell BOSS-N1 Dual M.2 NVMe SSD PCIe Card
Thanks for the request. We'll get back to you with in 24 hours.
Boot Device Specs
| BOSS card | Drive Size | RAID levels | Stripe size | Virtual disk cache functio n | Maximum number of virtual disks | Maximum number of drives supported | Drive types | PCIe support | Disk cache policy | Support for Non-RAID disks | Crypto graphic digital signature to verify firmware payload | Hot Plug |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BOSS-N1 Monolithic | M.2 devices are read-intensive with 480 GB or 960 GB capacity | RAID1 and RAID0 | Supports default 64K stripe size only | None | 1 | 2 | M.2 NVMe SSDs | Gen3 | Drive default | No | Yes | Yes |
BOSS-N1 is offered as a means of booting 16G servers to a full OS when the target OS is a full OS (not just a hypervisor), or the user does not wish to trade off standard hot plug drive slots for OS install The HW RAID BOSS-N1 card is a RAID controller with a limited feature set that presents M.2 NVMe-only SSDs as either a RAID0 disk or a single RAID1 volume with 2 disks. BOSS-N1 enables support for 480/960 GB Disks from Factory Install.
Hardware: BOSS-N1 Controller and Carrier (x2) Reliability: Enterprise-Class M.2 NVMe SSDs
Supports dual 80 mm, Read Intensive (1DWPD), M.2 devices 480 GB/960 GB Standard - 1.92 TB QNS
Accessibility: Rear Facing
Serviceability: Full Hot-Plug Support
Supports Hardware RAID1 and RAID0
Supports UEFI boot
Marvell 88NR2241 NVMe RAID Controller
Controlled Firmware Upgrade through iDRAC
- Dell Mx760c
- Dell R660xs
- Dell XR4000
- Dell XR5610
- Dell XR7620
- Dell XR8000
