-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.
Quick Specs
LFF:
- 144 TB (single LFF array-head -using 12 x 12TB LFF SAS MDL drives)
- 576 TB (by adding 3 LFF Disk Enclosures behind LFF Array & using 12 TB LFF SAS MDL drives)
SFF:
- 76.8 TB (single SFF array-head - using 24 x 3.2TB SFF SSD drives)
- 307.2 TB (by adding 3 SFF Disk Enclosures behind SFF Array & using 3.2TB SFF SSD drives)
Host Interconnect:
- 2 x 8Gb Fibre Channel ports per controller
- 2 x 1GbE RJ-45 ports per controller
- 2 x 10GbE ports per controller
- 2x 12Gb SAS ports per controller
The HPE MSA 1040 is a cost-effective storage array that delivers great value for businesses looking to optimize their storage infrastructure. It offers flexible connectivity options, including 8Gb Fibre Channel, 1GbE iSCSI, and 12Gb SAS, allowing users to choose the interface that best fits their needs. With support for up to 99 SFF (Small Form Factor) drives or 42 LFF (Large Form Factor) drives, it can accommodate various drive types and capacities to meet specific performance and capacity requirements. The MSA 1040 is known for its simplicity, making it easy to deploy and manage storage resources efficiently.
The HPE MSA 1040 Storage is designed for entry-level market needs and features 8Gb Fibre Channel, 12 Gb SAS, 1GbE, and 10GbE iSCSI at previously unattainable entry price points. The array allows users to take advantage of the latest storage technologies in simple and efficient ways by providing a good balance between performance and budget resulting in a highly favorable $/GB return on their investment.
Entry consolidation and virtualization initiatives are now well within your budgetary reach. The MSA 1040 offers many MSA 2040 features but at a more affordable entry price point. ProLiant and Blade Systems administrators as well as IT generalists will find storage management tasks simple and intuitive with MSA.
The MSA 1040 Arrays are designed to allow an installation to begin with a smaller capacity and be able to grow gradually as needed. The flexibility of SAS or SAS MDL drives technology, form factors, sizes, speeds, and costs per GB allows a system to easily fit into almost any budget.
The MSA 1040 arrays come integrated with a web browser and CLI-based software for storage and RAID management, setup, configuration, and troubleshooting. This reduces the cost of ownership by reducing the training and technical expertise necessary to install and maintain your HPE storage solution.
