Dell PowerEdge XE7745

The Dell PowerEdge XE7745 is a 4U dual-socket, air-cooled AI server built around PCIe accelerators, aimed at AI inferencing, model fine-tuning and AI-powered HPC. It holds up to eight double-wide 600W PCIe Gen5 GPUs, such as the NVIDIA H200 NVL, H100 NVL, RTX Pro 6000 or AMD MI350P, or up to sixteen single-wide 75W cards like the L4. Two 5th Gen AMD EPYC 9005 processors with up to 192 cores each drive 24 DDR5 RDIMM slots for up to 3TB at up to 6400 MT/s. Eight more front PCIe Gen5 x16 slots serve cluster networking, alongside an optional OCP 3.0 card, up to 8x E3.S Gen5 NVMe SSDs and BOSS-N1 boot. Hot-swap fans, Titanium 3200W or 2400W PSUs in separate CPU and GPU zones and iDRAC10 round it out. Fully configurable.

Looking to compare generations? See the Gen 16 Dell PowerEdge XE9680, Dell PowerEdge XE9680L, Dell PowerEdge XE9640 and Dell PowerEdge XE8640, or compare Gen 17 models: Dell PowerEdge R7725, Dell PowerEdge R7725xd and Dell PowerEdge XE9780.

Thanks for the request. We'll get back to you with in 24 hours.

  • Form Factor: 4U Rack
  • Processors: Up to 2x 5th Gen AMD EPYC 9005 (up to 192 cores)
  • Memory: 24x DDR5 RDIMM slots, up to 3TB
  • Memory Speed: Up to 6400 MT/s
  • Storage: Up to 8x E3.S Gen5 NVMe SSDs
  • Expansion: 8x PCIe Gen5 x16 slots for networking, plus GPU slots
  • GPU Support: Up to 8x DW 600W or 16x SW 75W PCIe Gen5 GPUs
  • Networking: 1x OCP 3.0 (optional), dedicated iDRAC port
  • Management: iDRAC10
  • Cooling: Air, hot-swap mid-tray and front fans
  • Power: Titanium 3200W or 2400W PSUs, CPU and GPU zones

Thanks for the request. We'll get back to you with in 24 hours.

Configure this  XE7745 →

Customize & Get Pricing

Configure your Dell PowerEdge XE7745 with the exact specs you need

Configure This Server

Dell PowerEdge XE7745 vs XE9680: Specs & Key Differences

Feature PowerEdge XE7745 PowerEdge XE9680
Processors Up to 2x 5th Gen AMD EPYC 9005 (up to 192 cores) Up to 2x 4th/5th Gen Intel Xeon Scalable (up to 64 cores)
Memory 24x DDR5 RDIMM slots, up to 3TB 32x DDR5 RDIMM slots, up to 4TB
Memory Speed Up to 6400 MT/s Up to 5600 MT/s
Storage Up to 8x E3.S Gen5 NVMe SSDs Up to 8x 2.5" SAS/SATA/NVMe or 16x E3.S NVMe SSDs
PCIe 8x PCIe Gen5 x16 (NIC) plus GPU slots Up to 10x PCIe Gen5 x16
GPU Support 8x DW 600W or 16x SW 75W PCIe Gen5 GPUs 8x NVIDIA H100/H200/H20 SXM5, AMD MI300X or Intel Gaudi 3
Networking 1x OCP 3.0 (optional), dedicated iDRAC port 2x 1GbE LOM, 1x OCP 3.0 (x8)
Management iDRAC10 iDRAC9
Cooling Air Air
Power Up to 8x Titanium 3200W or 2400W (CPU + GPU zones) 6x Titanium 2800W or 3200W (5+1 or 3+3)
Form Factor 4U Rack 6U Rack

Frequently Asked Questions

Up to eight double-wide PCIe Gen5 accelerators at up to 600W or sixteen single-wide 75W cards. Dell lists the AMD MI350P and NVIDIA H200 NVL, H100 NVL, RTX Pro 6000, RTX Pro 4500, L40S and L4.

Two 5th Gen AMD EPYC 9005 Series processors with up to 192 cores and 500W each, and 24 DDR5 RDIMM slots (12 per socket) at up to 6400 MT/s. Dell's spec sheet lists up to 3TB of memory.

Up to eight EDSFF E3.S Gen5 NVMe SSDs and BOSS-N1 with two M.2 NVMe SSDs for boot, with no RAID controller. Eight front-serviceable PCIe Gen5 x16 slots handle back-end cluster networking, plus an optional OCP 3.0 NIC. Please specify your capacity needs when you submit your quote configuration.

It is fully air cooled, with four dual-fan modules in the mid tray and up to twelve fans at the front, all hot-swap. Titanium 3200W or 2400W power supplies are split between a CPU zone and a GPU zone; full redundancy uses 1+1 in the CPU zone and 3+3 in the GPU zone.

The 4U XE7745 uses up to eight standard PCIe GPUs on AMD EPYC 9005 with up to 192 cores per socket, DDR5-6400 and iDRAC10. The 6U Gen 16 XE9680 uses eight SXM or OAM accelerators such as NVIDIA H200 or AMD MI300X on Intel Xeon, with up to 4TB of memory and 2.5-inch drive options.
