Dell PowerEdge T140 Tower Server Chassis (4x3.5")


Price: Request a Quote

Brand:
MPN:
DPE-T140-4x3.5-Chassis
Type:
Chassis
Condition:
ECS Refurbished & Tested

Request Quote

Note: Please include as much details and relevant options about the item to help us match your request with an accurate price.


-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.

Dell PowerEdge T140 Tower Server Chassis (4x3.5")

Quick Specs

Form Factor:

Tower server

Processor | Max: N/A

1x Intel E-2200, Core i3, or Celeron

Memory | Max: 64GB

4 DDR4 UDIMM 2666Mhz

Storage | Max: 4TB

4 LFF Cabled Drives

Boot Options

Boot Optimized Server Storage (BOSS)

RAID Controller:

S140 (SW RAID)
PERC H730P, H330, HBA330 (non-RAID), 12Gbps SAS HBA (non-RAID)

NIC/LOM

2 x 1GbE LOM

Remote Management:

iDRAC9

PCIe Slots: 4

1x8 Gen3 (x16 connector) FH/HL
1x8 Gen3 (x8 connector) FH/HL
1x4 Gen3 (x8 connector) FH/HL
1x1 Gen3 (x1 connector) FH/HL

GPU:

Not Supported

The PowerEdge T140 is the easy to use, safe, and practical entry-level one-socket server for your growing business

Make IT easy

The Dell EMC PowerEdge T140 is easy to set up and easy to use, allowing you to focus on your business. The PowerEdge T140 enables you to work on your everyday business applications efficiently. The PowerEdge T140 can also conveniently be used in various locations due to enhanced 14G thermal efficiency and quiet acoustics. The PowerEdge T140 enables you to work on your everyday business applications efficiently such as file and print, mail and messaging and point of sale.

  • Work more efficiently with improved performance due to 50% more cores with Intel Xeon E-2200 processors, 11% increase in memory speed, and 20% more PCIe lanes.1
  • Get set up as much as 66% faster with our ProDeploy suite of services.
  • Work in wider operating temperature and humidity levels with Fresh Air 2.0 capable hardware.

Intuitive system management with intelligent automation

PowerEdge servers with embedded iDRAC with Lifecycle Controller offer agent-free management right out of the box, delivering smart automation of routine tasks. The T140 is easily managed which frees up time for work priorities.

  • Simplify management with the New OpenManage Enterprise console, with customized reporting and automatic discovery.
  • Resolve issues with less IT effort with ProSupport Plus and SupportAssist proactive and predictive technology.

Your practical, entry-level server

The Dell EMC PowerEdge T140 allows you to focus on your business, that’s why we offer the entry-level practical business server. Organize your data in one central data repository.

Cooling & Fans

The Dell EMC PowerEdge T140 system supports the following:

  • One system cooling fan located at the back of the system.
  • One processor cooling fan located on the heat sink.
Memory Options

Supported memory speeds are:

  • 2666 MT/s
  • 2400 MT/s
  • 2133 MT/s
DIMM type DIMM Rank DIMM Capacity Minimum RAM Maximum RAM
UDIMM Single rank 8 GB 8 GB 32 GB
16 GB 16 GB 64 GB
Dual rank 8 GB 8 GB 32 GB
16 GB 16 GB 64 GB
PCI Configurations

The Dell EMC PowerEdge T140 system supports up to four PCI express (PCIe) Generation 3.

PCIe slot Processor Connection PCIe slot height PCIe slot length Slot width
Slot 1 (Gen3) Processor Full Height Half Length x8 link in x8 slot
Slot 2 (Gen3) Processor Full Height Half Length x8 link in x16 slot
Slot 3 (Gen3) Platform Controller Hub Full Height Half Length x1
Slot 4 (Gen3) Platform Controller Hub Full Height Half Length x4 link in x8 slot
Networking

The Dell PowerEdge T140 comes with a 2 Port 1GbE LOM card installed. You can access this lom card from the back of the Tower Server. You also have the ability to install up to 4 PCIe adapters in the slots discussed above.

You can locate the LOM ports by looking at the Rear image of the server above.

Storage Controllers

The system comes with Software RAID: PERC S140. You also have the Boot Options of the (BOSS) Card. This boss card holds up to 2x M.2 240GB (RAID 1 or No RAID) or 1x M.2 240GB (No RAID only)

Internal Controllers External Controllers
● PERC H730P
● PERC H330
● HBA330
● 12 Gb/s Ext SAS HBA
● HBA355e
Power & Dimensions
Power Supply Unit (PSU)

The Dell PowerEdge T140 only has 1 Cabled PSU in the back of the Tower Server. The only option for power is a Single cabled 365W PSU

Dimensions
  • Chassis height: 360mm (14.17 in)
  • Chassis width: 175mm (6.89 in)
  • Chassis depth: 454 mm (17.9 in)
  • Chassis weight: 11.84 kg (26.10 lb.)

Looking to Customize?

Need assistance with customization? Our sales experts will help you choose the best setup for your needs.

Start Customizing Today!

Product Specs

Base Standard Capabilities

FeaturePowerEdge T140 Technical specification
Processor1 processor from the following: Intel® Xeon® E-2200 product family, Intel Pentium®, Intel Core i3®, Intel Celeron®
Memory4x DDR4 DIMM slots, supports UDIMMs, speeds up to 2666MT/s, 64GB max. supports registered ECC.
Storage controllersInternal controllers: PERC H730P, H330, HBA330 (non-RAID)
Software RAID: PERC S140
External HBAs: 12Gbps SAS HBA (non-RAID)
Boot Optimized Storage Subsystem (BOSS): 2x M.2 240GB (RAID 1 or No RAID), 1x M.2 240GB (No RAID only)
Drive baysUp to 4 x 3.5” cabled bays
Power suppliesSingle cabled 365W PSU
DimensionsForm factor: Mini tower serverChassis height: 360mm (14.17 in)
Chassis width: 175mm (6.89 in)
Chassis depth: 454 mm (17.9 in)
Chassis weight: 11.84 kg (26.10 lb.)
Embedded managementiDRAC9 with Lifecycle Controller
iDRAC Direct
iDRAC RESTful API with Redfish
OpenManage SoftwareOpenManage Enterprise
OpenManage Essentials
OpenManage Power Center
OpenManage Mobile
requires OM Enterprise or OM Essentials)
Integrations and connectionsIntegrations:
Microsoft® System Center
VMware® vCenter™
BMC Truesight (available from BMC)
Red Hat Ansible
Connections:
Nagios Core & Nagios XI
Micro Focus
Operations Manager i (OMi)
IBM Tivoli Netcool/OMNIbus
ToolsiDRAC Service Module
OpenManage Server Administrator
Dell EMC Repository Manager
Dell EMC System Update
Dell EMC Server Update Utility
Dell EMC Update Catalogs
Dell EMC RACADM CLI
IPMI Tool
SecurityTPM 1.2/2.0 optional
Cryptographically signed firmware
Silicon Root of Trust
Secure Boot
System Lockdown (requires OpenManage Enterprise)
Secure Erase
I/O & PortsNetworking options:
2 x 1GbE LOM
Front Ports: 1x USB 3.0, 1x iDRAC micro USB 2.0
management port
Rear Ports: 2x USB 3.0, 4x USB 2.0, VGA, serial
connector
Internal USB: 1x internal USB 3.0
4 PCIe Slots:
1x8 Gen3 (x16 connector) FH/HL
1x8 Gen3 (x8 connector) FH/HL
1x4 Gen3 (x8 connector) FH/HL
1x1 Gen3 (x1 connector) FH/HL
Supported operating systemsCertify XenServer
Citrix® XenServer®
Microsoft Windows Server® with Hyper-V
Red Hat® Enterprise Linux
Ubuntu Server
SUSE® Linux Enterprise Server
VMware® ESXi
For specifications and interoperability details,
see Dell.com/OSsupport.
OEM-ready version availableFrom bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you.
For more information, visit Dell.com/OEM.
Recommended supportProSupport Plus for critical systems or ProSupport for comprehensive hardware and software support for
your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell EMC
representative today for more information. Availability and terms of Dell EMC Services vary by region.
For more information, visit Dell.com/ServiceDescriptions.
