HPE ProLiant DL180 (G10) 4208 2.1GHz 8 Core 1P 16GB-R P816i-A 12LFF 500W PS Server | P37151-B21

Refurbished HPE ProLiant DL180 Gen10 Configure to Order Server

SKU: P37151-B21

HPE ProLiant DL180 (G10) 4208 2.1GHz 8 Core 1P 16GB-R P816i-A 12LFF 500W PS Server | P37151-B21

Name: HPE ProLiant DL180 (G10) 4208 2.1GHz 8 Core 1P 16GB-R P816i-A 12LFF 500W PS Server | P37151-B21
Brand: HPE
SKU: P37151-B21
Availability: InStock

HPE

| Server

.price-ui--loading { display: block !important; opacity: 1 !important; }

Contact For Pricing

Thanks for the request. We'll get back to you with in 24 hours.

-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.

-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.

Comes with:

Processors - 1 x 4208 (2.1GHz/8-core/85W)
Memory - HPE 16GB 1Rx4 PC4-2933Y-R Smart Kit
Network Controller - Embedded 2-Port 1GbE
Storage Controller - P816i-a and Smart Storage Battery
Cables - HPE DL180 Gen10 LFF P816i-a Cable Kit (P36415-B21)
Hard Drive - None included
Optical Drive - None included
PCIe Slots - 3 PCIe: 1x8 FHFL, 1x8 FHHL, 1x8 FHHL
Power Supply - 1x 500W Hot Plug; RPS ready
Fans - 3 Fans
Management - HPE iLO5, Infosight
Energy Start - N/A
Form Factor - Rack (2U), LFF Easy Install

Looking to Customize?

Not seeing the exact specs you need?
Start your build today with Express Computer Systems!

Start Customizing Today!

Base Standard Capabilities

Product features

Feature

Description

Form factor

2U rack

Chassis types

8 Small Form Factor (SFF)
8 LFF

System fans

Standard - Fan types	Non-Redundant	Redundant
1P Model	3 Fans (4,5,6)	4 Fans (2,4,5,6)
2P Model	5 Fans (2,3,4,5,6)	6 Fans (1,2,3,4,5,6)

Chipset

Intel C622 chipset

On system management chipset

HPE Integrated Lights-Out (HPE iLO) 5 ASIC

Processors

Intel Xeon Models	CPU Frequency	Cores	L3 Cache	Power	UPI	DDR4	Memory per socket
Silver Processors
Silver 4110 Processor	2.1 GHz	8	11.00MB	85 W	2 @ 9.6 GT/s	2400 MT/s	768GB
Bronze Processors
Bronze 3106 Processor	1.7 GHz	8	11.00MB	85 W	2 @ 9.6 GT/s	2133 MT/s	768GB

Memory

One of the following depending on model

Type	HPE DDR4 SmartMemory, Registered Dual In-line Memory Module (RDIMM)
Dual In-line Memory Module (DIMM) slots available	8 DIMM slots per processor, 6 channels per processor, 2 channels - 2 DIMMs per channel, 4 channels - 1 DIMM per channel
Maximum capacity (RDIMM)	16 x 16 GB RDIMM - 2400 MT/s

Memory protection

For details on the HPE Server memory options RAS feature, visit: Click here to view the Memory RAS technologies for HPE ProLiant/Synergy/Blade Gen10 servers with Intel Xeon Scalable processors for more infomration .

Storage controllers

The Gen10 controller naming framework has been updated to simplify identification as depicted below. For a more detailed breakout of the available Gen10 Smart Array controllers visit the HPE Smart Array Gen10 Controllers Data Sheet .

Software RAID

HPE Smart array S100i SR Gen10 SW RAID

Essential RAID controller

HPE Smart Array E208i-p SR Gen10 controller
HPE Smart Array E208e-p SR Gen10 controller
HPE Smart Array E208i-a SR Gen10 controller

Performance RAID controller

HPE Smart Array P408i-a SR Gen10 controller

Internal storage devices

One of the following depending on model

Hard drives

None ship standard

Maximum internal storage

Maximum Internal Storage	Capacity	Configuration
Hot Plug SFF SAS	9.6TB	8 X 1.2TB
Hot Plug SFF SAS SSD	3.2TB	4 X 400GB
Hot Plug SFF SATA SSD	3.8TB	4 X 480GB
Hot Plug LFF SAS HDD	32TB	8 X 4TB
Hot Plug LFF SATA HDD	32TB	8 X 4TB

Interfaces

Video

1 Rear - VGA Port (Standard)

Network ports

2 x 1Gb ports shipping standard with optional media module, FlexibleLOM or stand up card

Management Network Port

1Gb Dedicated

Front iLO service port

1 Standard

Micro SD slot

1 Micro SD

Industry standard compliance

ACPI 6.1 compliant
PCIe 3.0 compliant
WOL support
Microsoft logo certifications
Preboot Execution Environment (PXE) support
USB 3.0 compliant (Internal)
System Management BIOS (SMBIOS) 3.1
UEFI 2.6
Redfish API
IPMI 2.0
Secure digital 2.0
Advanced Encryption Standard (AES)
Triple Data Encrytion Standard (3DES)
SNMP v3
TLS 1.2
DMTF Systems Management Architecture for Server Hardware Command Line Protocol (SMASH CLP)
Active directory v1.0
ASHRAE A3/A4

Graphics integrated video standard

Video modes up to 1920 x 1200 - 60 Hz (32 bp)
16MB video memory

HPE iLO 5 on system management memory

32MB Flash
4 Gbit DDR 3 with ECC protection

HPE Server Unified Extensible Firmware Interface (UEFI)/legacy ROM

UEFI is an industry standard that provides better manageability and more secured configuration than the legacy ROM while interacting with users server at boot time. HPE ProLiant Gen10 servers have a UEFI Class 2 implementation and support both UEFI mode (Default) and legacy BIOS mode.

Secure boot and secure start enable for enhanced security
Operating System (OS) specific functionality
Support for > 2.2TB (Using GPT) boot drives
USB 3.0 stack
Embedded UEFI shell
Mass configuration deployment tool using iLO RESTful API that is Redfish API conformant
PXE boot support for IPv6 networks
Workload Profiles for simple performance optimization

UEFI boot mode only:

iSCSI software initiator support.
HTTP/HTTPs boot support as a PXE alternative.

Boot support for option cards that only support a UEFI option ROM

Embedded Management

HPE iLO
UEFI
Intelligent provisioning
iLO RESTful API

Server utilities

Active health system
Active health system viewer
Smart update
Service Pack for ProLiant (SPP)
iLO amplifier pack
HPE iLO mobile application
RESTful interface tool
Scripting tools
HPE Systems Insight Manager (HPE SIM)

Security

UEFI secure boot and secure start support
Immutable silicon root of trust
FIPS 140-2 validation (iLO 5 Certification in progress)
Common criteria certification (iLO 5 Certification in progress)
Configurable for PCI DSS compliance
AES and Triple Data Encryption Standard (3DES) on browser
Support for Commercial National Security Algorithms (CNSA)
Tamper-Free updates - Components digitally signed and verified
Secure recovery - Recover critical firmware to known good state on detection of compromised firmware
Ability to rollback firmware
Secure erase of NAND/User data

Expansion slots

Expansion Slots CPU1 x8x8x8 riser Slots #	Technology	Bus Width	Connector Width	Slot Form Factor	Notes
1	PCIe 3.0	X8	X8	Full-Height, Full-Length slot	Proc 1
2	PCIe 3.0	X8	X8	Full-height, Half-Length slot	Proc 1
3	PCIe 3.0	X8	X8	Full-Height, Half-Length slot	Proc 1

FlexibleLOM Slots #	Technology	Bus Width	Connector Width	Slot Form Factor	Notes
1	PCIe 3.0	X8	X8	Full-Height, Full-Length slot	Proc 1
2	PCIe 3.0	X8	X8	Full-height, Half-Length slot	Proc 1
3	PCIe 3.0	X8	X8	FlexibleLOM	Proc 1

CPU1 x16x8 riser Slots #	Technology	Bus Width	Connector Width	Slot Form Factor	Notes
1	PCIe 3.0	X16	X16	Full-Height, Full-Length slot	Proc 1
2	PCIe 3.0	X8	X8	Full-height, Half-Length slot	Proc 1

Expansion Slots CPU2 x8x8x8 riser Slots #	Technology	Bus Width	Connector Width	Slot Form Factor	Notes
1	PCIe 3.0	X8	X8	Full-Height, Full-Length slot	Proc 2
2	PCIe 3.0	X8	X8	Full-height, Half-Length slot	Proc 2
3	PCIe 3.0	X8	X8	Low profile	Proc 2

top

Specs 1

Software overview

Feature	Description
OS and virtualization software support for ProLiant servers	Windows server 2019 (Tested only) Windows Server 2016 VMware vSphere 6.0 U3 VMware vSphere 6.5 U2 Red Hat Enterprise Linux (RHEL) 7.6 (With Kbase) SUSE Linux Enterprise Server 12 SP4

top

Physical specifications

Specification	Description
Dimensions (H x W x D)	8.75 x 44.54 x 63.47 cm (3.44 x 17.54 x 24.99 in)
Weight (Approximate)	Minimum: 8 SFF/LFF chassis with 1x SFF/LFF HDD and 7 HDD blanks, 2x drive bay blanks, 1x processor including standard heatsink, 1x power supply (Plus blank), 1x smart array, 1x riser installed, cables for the above) 26.0 kg (58.0 lb)

top

Electrical specifications

Specification	Description
Input requirements	Rated line voltage 100 to 120 V ac 200 to 240 V ac
BTU rating	Maximum: For 500 W Power supply: 1979 BTU/hr (At 100 V ac), 1911 BTU/hr (At 200 V ac), 1965 BTU/hr (At 240 V ac) for china only
Power supply output	Rated Steady-State power For 500 W Power supply: 500 W (At 100 V ac), 500 W (At 240 V ac), 500 W (At 240 V ac) input for china only

top

Environmental specifications

Specification

Description

System inlet temperature

10° to 35° C (50° to 95° F)

Extended ambient operating support

5° to 10° C (41° to 50° F) and 35° to 40° C (95° to 104° F)

Non-Operating temperature

-30° to 60° C (-22° to 140° F). Maximum rate of change is 20°C/hr (36°F/hr)

Operating relative humidity

8% to 90% - Relative humidity, 28°C maximum wet bulb temperature, Non-Condensing

Non-Operating relative humidity

5 to 95% - Relative humidity, 38.7°C (101.7°F) maximum wet bulb temperature, Non-Condensing

Operating altitude

3050 m (10,000 ft)

Non-Operating altitude

9144 m (30,000 ft)

Acoustic noise

Listed are the declared A-Weighted sound power levels (LWAd) and declared average bystander position A-Weighted sound pressure levels (LpAm) when the product is operating in a 23°C ambient environment. Noise emissions were measured in accordance with ISO 7779 (ECMA 74) and declared in accordance with ISO 9296 (ECMA 109). The listed sound levels apply to standard shipping configurations. Additional options may result in increased sound levels. Please have your HPE representative provide information from the HPE EMESC website for further technical details regarding the configurations listed below.

Configuration SKU	Entry(LFF)	Base(LFF)	Performance(LFF)
Configuration SKU	Entry(SFF)	Base(SFF)	Performance(SFF)
Idle
LWAd	4.2 B	4.3 B	4.7 B
LpAm	26.6 dBA	27.0 dBA	28.5 dBA
Operating
LWAd	5.2 B	5.4 B	5.7 B
LpAm	35.4 dBA	37.2 dBA	39.7 dBA

top

Safety certifications

Specification	Description
Emissions Classification (EMC)	To view the regulatory information for users product, view the safety and compliance information for server, storage, power, networking, and rack products, available at the Hewlett Packard Enterprise Support Center: Hewlett Packard Enterprise Support Center for Enterprise Safety and Compliance .

top

Spec Sheet 4

Technical specifications	HPE ProLiant DL180 Gen10 server
Processor family	Intel® Xeon® Scalable 3200-8200 series & Intel® Xeon® Scalable 3100-6100 series
Processor core available	4 to 26 core, depending on processor
Processor cache	8.25-35.75 MB L3, depending on processor
Processor speed	3.8 GHz maximum depending on processor
Power supply type	Up to 2 HPE Flexible Slot Power Supplies
Expansion slots	6, for detailed descriptions reference the QuickSpecs
Maximum memory	1.0 TB with 64 GB DDR4
Memory slots	16 DIMM slots
Memory type	HPE DDR4 SmartMemory
Included hard drives	None ship standard, 8-12 LFF drives and 8-24 SFF drives supported, optional rear 2SFF drives
Optical drive type	Optional: DVD-ROM or DVD-RW
System fan features	Standard single rotor hot swap fans
Network controller	HPE embedded 2-port 1 GbE Ethernet adapter and optional HPE FlexibleLOM, Media Module Adapter, or PCIe stand-up card
Storage controller	HPE Smart Array S100i and/or HPE Essential or Performance RAID controllers, depending on model
Product Dimensions (imperial)	3.44 x 17.54 x 24.99 in
Weight	28.0 lb minimum, 58.0 lb maximum
Infrastructure management	HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download), Optional- HPE iLO Advanced, and HPE OneView Advanced (require licenses)
Drive supported	8-24 SFF SAS/SATA HDD/SSD, 8-12 LFF SAS/SATA HDD/SSD, optional rear 2SFF SAS/SATA HDD/SSD depending on model
