Dell PowerEdge R6625 Rack Server Chassis (4x 3.5")

SKU: DPE-R6625-4LFF-Chassis

Dell PowerEdge R6625 Rack Server Chassis (4x 3.5")

Name: Dell PowerEdge R6625 Rack Server Chassis (4x 3.5")
Brand: Dell
SKU: DPE-R6625-4LFF-Chassis
Availability: InStock

Dell

| Chassis

.price-ui--loading { display: block !important; opacity: 1 !important; }

Contact For Pricing

Thanks for the request. We'll get back to you with in 24 hours.

Quick Specs

Form Factor:

1U rack server

Processor | Max: 128 Cores

2x 4th Gen AMD 9004 Series

Memory | Max: 6TB

24 ECC DDR5 RDIMM 4800Mhz

Storage | Max: 153.6TB

4x LFF SAS/SATA (HDD/SSD) | Max: 80TB

Rear Drives | Max: 30.72TB

2x SFF SAS/SATA (HDD/SSD) NVMe | Max: 30.72TB
2x EDSFF E3.S Gen5 NVMe (SSD) | Max: 12.8TB

Storage Controller:

S160(SW RAID)
H965i, H755, H755N, H355, HBA355i, HBA355e, HBA465e, H965e

Boot Options:

BOSS-N1 (hot Swap)
Internal USB

Networking Options (NOC):

1 x OCP card 3.0 (supported by x8 PCIe lanes)
2x 1Gb with BCM5720 LAN controller
Note: The system allows either LOM card or an OCP card or both to be installed in the system.

Remote Management:

iDRAC9 with Lifecycle Controller

PCIe Slots:

2x or 3x PCIe 4.0 & 5.0

GPU:

Up to 3 x 75 W SW

Other Versions

Ideal for:

High-Performance Computing (HPC)
Virtual Desktop Interface (VDI)
Virtualization

The new Dell PowerEdge R6625 is a 1U, dual-socket rack server. Designed to be the backbone of your data center, this powerful server provides ample performance and flexible, low-latency storage options in a dense air or Direct Liquid Cooling (DLC) configuration.

Extreme performance in a platform that grows with your business

Using AMD EPYC 4th generation processor to deliver up to 50% more core count per single socket platform in an innovative air or liquid-cooled chassis.
Enables DDR5 at 4800 MT/s memory and PCIe Gen5 with double the speed of previous Gen4 for faster access and transport of data optimizing application output.
Optional DLC is available to more efficiently cool high-performance processors

Stay ahead of the curve

Delivering breakthrough innovation using the latest performance, density and optional acceleration for traditional and emerging workloads including high-performance compute (HPC), virtual desktop integration (VDI) and virtualization.

Cyber Resilient Architecture for Zero Trust IT environment & operations

Security is integrated into every phase of the PowerEdge lifecycle, including protected supply chain and factory-to-site integrity assurance. Silicon-based root of trust anchors end-to-end boot resilience while Multi-Factor Authentication (MFA) and role-based access controls ensure trusted operations.

Experience more virtual machine density to support the most demanding applications

Deliver more virtual machines per physical host using increased core count and higher memory footprint than previous generations.
Improve responsiveness or reduce app load time for power users with up to 3 x single-wide full-length GPUs.

Expect increased expandability by storing more data in one server, saving space in your data center

Scale your storage using up to 60% more E3.S NVMe drives and reduce your carbon footprint.
Deliver more memory density with DDR5 (up to 6 TB of RAM) providing greater memory capacity.
Support lower latency higher performance NVMe SSD in a hardware RAID solution helps maximize compute performance.

Looking to Customize?

Need assistance with customization? Our sales experts are here to help you.

Start Customizing Today!

Base Standard Capabilities

Feature	Technical Specifications
Processor	Up to two AMD EPYC 4th Generation 9004 Series with up to 128 cores per processor
Memory	• 24 DDR5 DIMM slots, supports RDIMM 6 TB max, speeds up to 4800 MT/s • Supports registered ECC DDR5 DIMMs only
Storage controllers	• Internal Controllers: PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355i • Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSDs or USB • External HBAs (non-RAID): HBA355e • Software RAID: S160
Drive Bays	Front bays: • Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 80 TB • Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB • Up to 10 x 2.5-inchSAS/SATA/NVMe (HDD/SSD) max 153.6 TB • Up to 14 x E3.S NVMe direct drives max 89.6 TB • Up to 16 x E3.S NVMe direct drives max 102.4 TB Rear bays: • Up to 2 x 2.5-inch SAS/SATA (HDD/SSD) max 30.72 TB • Up to 2 x E3.S NVMe direct drives max 12.8 TB
Power Supplies	• 1800 W Titanium 200—240 VAC or 240 HVDC, hot swap redundant • 1400 W Mixed mode 100—240 VAC or 240 HVDC, hot swap redundant • 1100 W Mixed mode 100—240 VAC or 240 HVDC, hot swap redundant • 1100 W LVDC -48 — -60 VDC, hot swap redundant • 800 W Platinum 100—240 VAC or 240 HVDC , hot swap redundant
Cooling Options	• Air cooling • Optional Direct Liquid Cooling (DLC) Note: DLC is a rack solution and requires rack manifolds and a cooling distribution unit (CDU) to operate.
Fans	• Standard (STD) fans/High performance Gold (VHP) fans • Up to 4 sets (dual fan module) hot plug fans
Dimensions	• Height – 42.8 mm (1.685 inches) • Width – 482.0 mm (18.97 inches) • Depth – 822.89 mm (32.4 inches) with bezel - 809.05 (31.85 inches) without bezel
Form Factor	1U Rack server
Embedded Management	• iDRAC9 • iDRAC Direct • iDRAC RESTful API with Redfish • iDRAC Service Manual • Quick Sync 2 wireless module
Bezel	Optional LCD bezel or security bezel
OpenManage Software	• OpenManage Enterprise • OpenManage Power Manager plugin • OpenManage Service plugin • OpenManage Update Manager plugin • CloudIQ for PowerEdge plug in • OpenManage Enterprise Integration for VMware vCenter • OpenManage Integration for Microsoft System Center • OpenManage Integration with Windows Admin Center
Mobility	OpenManage Mobile
OpenManage Integrations	• BMC Truesight • Microsoft System Center • OpenManage Integration with ServiceNow • Red Hat Ansible Modules • Terraform Providers • VMware vCenter and vRealize Operations Manager
Security	• AMD Secure Encrypted Virtualization (SEV) • AMD Secure Memory Encryption (SME) • Cryptographically signed firmware • Data at Rest Encryption (SEDs with local or external key mgmt) • Secure Boot • Secured Component Verification (Hardware integrity check) • Secure Erase • Silicon Root of Trust • System Lockdown (requires iDRAC9 Enterprise or Datacenter) • TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Embedded NIC	2 x 1 GbE LOM card (optional)
Network options	1 x OCP 3.0 card (optional) Note: The system allows either LOM card or an OCP card or both to be installed in the system.
GPU Options	3 x 75 W SW
Ports	Front Ports • 1 x iDRAC Direct (Micro-AB USB) port • 1 x USB 2.0 • 1 x VGA	Rear Ports • 1 x Dedcated iDRAC Ethernet port • 1 x USB 3.0 • 1 x USB 2.0 • 1 x Serial (optional) • 1 x VGA (optional for Direct Liquid Cooling configuration)
Ports	Internal Ports • 1 x USB 3.0 (optional)
PCIe	Up to three PCIe slots • Slot 1: 1 x16 Gen5 or 1 x16 Gen4 Low profile, Half length or 1 x16 Gen5 Full height, Half length • Slot 2: 1 x16 Gen5 or 1 x16 Gen4 Low profile, Half length or 1 x16 Gen5 Full height, Half length • Slot 3: 1 x16 Gen5 or1 x16 Gen4 Low profile, Half length
Operating System and Hypervisors	• Canonical Ubuntu Server LTS • Microsoft Windows Server with Hyper-V • Red Hat Enterprise Linux • SUSE Linux Enterprise Server • VMware ESXi

Specs 1

Rack Server	R760	R660	R7625	R6625	R7615	R6615
Key attributes	Provides performance and versatility for demanding applications	Provides performance and versatility for demanding applications	Breakthrough performance	Breakthrough performance	Powerful performance and scalability	Peak performance and excellent TCO
Target workloads	Mixed Workload Standardization Database and Analytics Virtual Desktop Infrastructure	High Density Virtualization, Dense Database Analytics, Mixed Workload Standardization	High Performance Computing (HPC), Virtual Desktop Infrastructure (VDI), Virtualization	High Performance Computing (HPC), Virtual Desktop Infrastructure (VDI), Virtualization	Software-Defined Storage (SDS), Virtualization, Data Analytics	Virtualization, Hyper-Converged Infrastructure (HCI), Network Functions Virtualization (NFV)
Type of processor	2 x 4th Generation Intel® Xeon® Scalable processors; up to 56 cores per processor		2 x AMD EPYC™ 4th Generation 9004 Series Processor, up to 96 cores per processor		1 x AMD EPYC™ 4th Generation 9004 series processor; up to 96 cores
Memory (DDR5 DIMM slots & max)	32 (8 TB)		24 (1.5 TB*)		12 (768 GB*)
Disk drives up to:	12 x 3.5” 8 x 2.5” 16 x 2.5” 24 x 2.5” 2 x 2.5” or 4 x 2.5” (rear)	8 x 2.5” 10 x 2.5” 2 x 2.5” (rear)	8 x 3.5” 12 x 3.5” 8 x 2.5” 16 x 2.5” 24 x 2.5” 2 x 2.5” or 4 x 2.5”(rear)	4 x 3.5” 8 x 2.5” 10 x 2.5” 2 x 2.5” (rear)	8 x 3.5” 12 x 3.5” 8 x 2.5” 16 x 2.5” 24 x 2.5” 2 x 2.5” or 4 x 2.5”(rear)	4 x 3.5” 8 x 2.5” 10 x 2.5” 2 x 2.5” (rear)
NVMe drives up to:	24	10	24	10	24	10
Gen5 PCIe slots up to:	4	2	4	2	4	2
Gen4 PCIe slots up to:	8	3	8	3	4	3
Accelerator support up to:	2 x 350 W DW or 6 x 75 W SW	2** x 75 W SW	2 x 300 W DW or 6 x 75 W SW	3 x 75 W SW	3 x 300 W DW or 6 x 75 W SW	3 x 75 W SW
Rack height (U)	2	1	2	1	2	1
Integrated security	TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ, Cryptographically Signed Firmware, Chassis Intrusion Alert, Secure Boot being standard security, Silicon Root of Trust, System Lockdown (requires iDRAC9 Enterprise or Datacenter), Data at Rest Encryption (SEDs with local or external key mgmt) Secured Component Verification (Hardware integrity check) and System Erase on all racks.			TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ, Cryptographically Signed Firmware, Secure Boot, Secure Erase, Silicon Root of Trust, System Lockdown (requires iDRAC9 Enterprise or Datacenter), AMD Secure Memory Encryption (SME) and AMD Secure Encrypted Virtualization (SEV)
* Future releases will include additional system capacity for DDR5 memory in R7625, R6625, R7615 and R6615. ** Future releases will include additional GPU slots in R660.

Spec Sheet 4

Features	PowerEdge R6625 (2S1U)		PowerEdge R6525 (2S1U)
Processors	Two AMD® EPYC 4th Generation Genoa (SP5) processors		Two AMD® EPYC™ Generation 2 or Generation 3 processors.
Processor interconnect	Inter-chip global memory interconnect (xGMI) 32GT/sec		Inter-chip global memory interconnect (xGMI) 16GT/sec
Memory	24x DDR5 RDIMM, 3DS DIMM DDR5 with ECC, bandwidth up to 4800 MT/s		32x DDR4 RDIMM, LRDIMM, 3DS
Storage Controllers	● PERC 11: HBA355i, H355, H755, H755N ● PERC 12: H965i ● Software RAID: S160 ● BOSS-N1		● PERC: H755N, H840, H745, HBA345, H345, HBA355, HBA355e ● Software RAID: S150 ● BOSS-S1 ● BOSS-S2
PCIe SSD	● Up to 12 (10+2) NVMe direct attach ● Up to 16 x E.3 Gen.5		Up to 10+2 PCIe SSD
Drive Bays	Front bays: ● Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 80 TB ● Up to 8 x 2.5-inch NVMe max 122.88 TB ● Up to 10 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 153.6 TB ● Up to 14 x E3.S (NVMe Gen5 ) max 89.6 TB ● Up to 16 x E3.S (NVMe Gen5 ) max 102.4 TB Rear bays: ● Up to 2 x 2.5-inch SAS/SATA (HDD/SSD) max 30.72 TB ● Up to 2 x E3.s (NVMe Gen5) max 12.8 TB		Front bays: ● Up to 4 x 3.5-inch SAS/SATA drives ● Up to 8 x 2.5-inch SAS/SATA drives ● Up to 10 x 2.5-inch SAS/SATA/NVMe drives Rear bays: ● Up to 2 x 2.5-inch SAS/SATA/NVMe drives
Power Supplies	● 1800 W Mixed Mode 100-240 VAC or 240 HVDC, hot swap redundant ● 1400 W Mixed Mode 100-240 VAC or 240 HVDC, hot swap redundant ● 1100 W Mixed Mode 100-240 VAC or 240 HVDC, hot swap redundant ● 1100 W LVDC -48 - -60 VDC, hot swap redundant ● 800 W Platinum 100-240 VAC or 240 HVDC , hot swap redundant		● 1400 W Mixed Mode 100-240 VAC or 240 HVDC, hot swap redundant ● 1100 W Mixed Mode 100-240 VAC or 240 HVDC, hot swap redundant ● 1100 W LVDC -48 - -60 VDC, hot swap redundant ● 800 W Platinum 100-240 VAC or 240 HVDC , hot swap redundant
Cooling Options	● Air Cooling ● Optional Direct Liquid Cooling (DLC)		● Air Cooling
Fans	Up to four sets (dual fan module) Standard (STD) / High Performance Gold (HPR Gold) hot plug fans		Up to four Standard (STD)/ High performance silver grade (HPR Gold (Silver)), or high performance gold grade (HPR Gold (Gold))
Dimension	Height - 42.8 mm (1.685 inches)		Height - 42.8 mm (1.685 inches)
	Width - 482.0 mm (18.97 inches)		Width - 482.0 mm (18.97 inches)
	Depth - 822.89 mm (32.4 inches) with bezel		Depth - 822.89 mm (32.4 inches) with bezel
	Depth - 809.05 (31.85 inches) without bezel		Depth - 809.05 (31.85 inches) without bezel
Form Factor	1U rack server		1U rack server
Embedded Management	● iDRAC9 ● iDRAC Direct ● iDRAC RESTful API with Redfish ● iDRAC Service Manual ● Quick Sync 2 wireless module		● iDRAC9 ● iDRAC Direct ● iDRAC RESTful API with Redfish ● iDRAC Service Manual ● Quick Sync 2 wireless module
Bezel	Optional LCD bezel or security bezel		Optional LCD bezel or security bezel
OpenManage Software	● OpenManage Enterprise ● OpenManage Power Manager plug-in ● OpenManage Services plug-in ● OpenManage Update Manager plug-in		● OpenManage Enterprise ● LC 3.x ● OpenManage Power Manager plug-in ● OpenManage Services plug-in ● OpenManage Update Manager plug-in
Mobility	OpenManage Mobile		OpenManage Mobile
Integrations and Connections	OpenManage Integrations ● BMC Truesight ● Microsoft System Center ● OpenManage Integration with ServiceNow ● Red Hat Ansible Modules ● Terraform Providers ● VMware vCenter and vRealize Operations Manager		OpenManage Integrations ● Microsoft System Center ● Windows Admin Center (WAC) ● ServiceNow ● Red Hat Ansible Modules ● VMware vCenter	● OM Integration with Microsoft System Center (OMIMSC) ● OM Integration with Vcenter/vROps
Security	● AMD Secure Encrypted Virtualization (SEV) ● AMD Secure Memory Encryption (SME) ● Cryptographically signed firmware ● Data at Rest Encryption (SEDs with local or external key mgmt ● Secure Boot ● Secured Component Verification (Hardware integrity check) ● Secure Erase ● Silicon Root of Trust ● System Lockdown (requires iDRAC9 Enterprise or Datacenter) ● TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ		● Cryptographically signed firmware ● Secure Boot ● Secure Erase ● Silicon Root of Trust ● System Lockdown (requires iDRAC9 Enterprise or Datacenter) ● TPM 1.2/2.0 (optional), TCM 2.0 optional ● AMD Secure Memory Encryption (SME) ● AMD Secure Encrypted Virtualization (SEV)
Embedded NIC	2 x 1GbE LOM (optional)		No LOM riser supported on R6525.
Networking Options	1 x OCP card 3.0 (optional) NOTE: The system allows either LOM card or an OCP card or both to be installed in the system.		OCP 3.0 SCFF (Small Card Form Factor)
GPU Options	2 x 75 W (SW)		● 2 x 75 W (SW/FH) ● 1 x 75 W (SW/FH) ● 3 x 75 W (SW/LP)
Ports	Front Ports ● 1 x iDRAC Direct (Micro-AB USB) port ● 1 x USB 2.0 ● 1 x VGA	Rear Ports ● 1 x Dedicated iDRAC Ethernet port ● 1 x USB 2.0 ● 1 x USB 3.0 ● 1 x Serial (optional) ● 1 x VGA (optional for Direct Liquid Cooling configuration)	Front Ports ● 1 x iDRAC USB (Micro-AB USB) ● 1 x USB 2.0	Rear Ports ● 1 x USB 3.0 ● 2 x USB 2.0
Ports	Internal Port: 1 x USB 3.0		Internal Port: 1 x USB 3.0
PCIe	Up to three PCIe slots on Riser cards ● 2 x PCIe Gen5 slots ● 3 x PCIe Gen4 slots		Up to three PCIe slots (4.0 x16)
Operating System and Hypervisors	● Canonical Ubuntu Server LTS ● Microsoft Windows Server with Hyper-V ● Red Hat Enterprise Linux ● SUSE Linux Enterprise Server ● VMware ESXi		● Canonical Ubuntu Server LTS ● Red Hat Enterprise Linux ● SUSE Linux Enterprise Server ● VMware ESXi ● Cent OS
