-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.
The HPE ProLiant DL360 Gen11 server is a rack-optimized 1U dense solution that delivers exceptional compute performance, upgraded high-speed data transfer rate, and memory depth with 2P compute capability. Powered by 4th Gen Intel® Xeon® Scalable processors with up to 60 cores, increased memory bandwidth, up to 8 TB of memory, and high-speed PCIe Gen5 I/O, the HPE ProLiant DL360 Gen11 server is a perfect rack-optimized, 1U 2P, dense solution for general-purpose virtualization workloads that require increased compute density with built-in security and flexibility.
The silicon root of trust anchors the server firmware to an HPE-exclusive ASIC, creating an immutable fingerprint for the Secure Intel Processor that must be matched exactly before the server will boot. The HPE ProLiant DL360 Gen11 server is an excellent choice for EDA, CAD, and VDI.
| Dl360 Gen 11 | BTO Models |
|---|---|
| SKU Number | P51932-B21 P51932-291 P51932-421 |
| Model Name | HPE ProLiant DL360 Gen11 5415+ 2.9GHz 8-core 1P 32GB-R NC 8SFF 800W PS Server |
| Chassis | HPE ProLiant DL360 Gen11 8SFF NC CTO Server (P52499- B21) |
| Processor | 5415+ (8 core, 2.9GHz, 150W) |
| Number of Processors | One with standard heatsink |
| Memory | 32 GB RDIMM 2Rx8 4800 MT/s (1x 32 GB) (P43328-B21) Notes: Runs at 4400 MT/s due to processor limitation. |
| Network Controller | Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE (P26253-B21) Notes: No embedded networking |
| Storage Controller | Embedded Intel® VROC SATA for HPE ProLiant Gen11, with 14 SATA ports (10-ports accessible); Choice of HPE modular Smart Array and PCIe plug-in controller |
| Hard Drive | None Included |
| Internal Storage | 8 SFF NC CTO Server (upgradeable to 8+2 SFF front) |
| PCIe Slots | 2-slots (x16 FH, x16 HH) as standard. Upgradeable to 3 rd slot in HH (or remove Slot 2 bracket to be FH at Slot 3) in a 2 nd processor configuration. All PCIe Slos are in design with up to 9.5” length. |
| Power Supply | 1x HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit (P38995-B21) (-B21 & -291) |
| 1x HPE 800W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit (865438-B21) (-421) | |
| Fans | 5 - Standard |
| Management | HPE iLO 6 |
| Security | Trusted Platform Module (TPM) 2.0 Notes: Enabling TPM 2.0 no longer requires TPM module option kit for Gen11 as it is an embedded feature and disabled on shipments to China. |
| Rail Kit | HPE Easy Install Rail 3 Kit; w/o CMA. Notes: Server does not support shelf mounted rail kits (“L” brackets). |
| Energy Star | Energy Star 3.0 |
| Form Factor | 1U Rack |
What's new
- Powered by 4th Gen Intel® Xeon® Scalable processors with next-generation technology that supports up to 60 cores at 350W, and 16 DIMMs for up to 8 TB of high bandwidth DDR5 memory up to 4800 MHz.
- 16 DIMMs per processor for up to 8 TB total DDR5 memory per server with increased performance, High Bandwidth Memory (HBM) support, and lower power requirements.
- Advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2 x16 PCIe Gen5 and 2 OCP slots.
- Includes the new HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly, from anywhere.
- Supports up to 2 single wide (SW) GPUs[1] to accelerate graphic intense workloads.
- Supports Smart Cooling Modules for highest thermal design points (TDPs).
Looking to Customize?
Not seeing the exact specs you need?
Start your build today with Express Computer Systems!
Start Customizing Today!
Base Standard Capabilities
| Technical specifications | HPE ProLiant DL360 Gen11 |
|---|---|
| Processor type | Intel |
| Processor family | 4th Generation Intel® Xeon® Scalable Processors |
| Processor number | 1 or 2 |
| Processor core available | 8 to 60 core depending on processor. |
| Processor cache | 12 - 60 MB L3. depending on processor |
| Processor speed | 3.7 GHz, maximum depending on processor. |
| Power supply type | HPE 500W Flex Slot Platinum Hot Plug Power Supply, HPE 800W Flex Slot Platinum Hot Plug Power Supply, HPE 800W Flex Slot Titanium Hot Plug Power Supply, HPE 1000W Flex Slot Titanium Power Supply, HPE 1600W Flex slot Platinum Hot Plug Power Supply, HPE 1600W DC Power supply, HPE 1600W Flex Slot -48VDC Hot Plug Power Supply, HPE 1800W-2200W Flex Slot Titanium Hot Plug Power Supply (to be available CQ4 2023), depending on model. |
| Expansion slots | Maximum 3 PCIe Gen5 slots and maximum 2 OCP 3.0 PCIe5 slots. |
| Maximum memory | 4.0 TB per socket. when populated with 256 GB DDR5 |
| Memory slots | 16 DIMM slots per socket |
| Memory type | HPE DDR5 SmartMemory |
| Memory protection features | HPE Fast Fault Tolerant Memory Advanced ECC Memory Online Spare Memory Mirrored Memory |
| Optical drive type | Optional - HPE 9.5mm SATA DVD-RW Optical Drive, HPE Mobile USB DVD-RW Drive. |
| System fan features | Standard Fan Kit (Q'ty 5), Standard Fan Kit (Q'ty 2) for 2nd Processor, Performance Fan Kit (Q'ty 7), Close Loop Liquid Cooling Heatsink & Fan kit, Direct Liquid Cooling Solution (Shipment will be available CQ3 2023), depending on model. |
| Network controller | Wide range of speeds, cabling, chipsets and form factors (PCIe stand-up adapter and OCP3.0). Please see QuickSpecs for network card choices. |
| Storage controller | Included - Embedded SATA controller (AHCI or Intel SATA software RAID controller) Optional - HPE Smart Array Gen11 Storage Controller in Variety of protocols -including NVMe-, port count, array utilities, and form factors (PCIe stand-up adapter and OCP3.0). Please see QuickSpecs for storage controllers selection |
| DIMM capacity | 16 GB to 256 GB |
| Infrastructure management | Included - HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download). Optional - HPE iLO Advanced, and HPE OneView Advanced |
| Drive supported | Up to 4 LFF SAS/SATA HDDs or SSDs. Up to 8+2 SFF SAS/SATA HDDs or SATA/SAS/NVMe U.3 SSDs, depending on model. Up to 20 EDSFF E3.s 1T NVMe SSD. Up to 2 RAID1 NVMe M.2 Boot device (Internal modular or external accessible from rear wall). |
