Base Standard Capabilities
| Item | Details |
|---|---|
| Chassis support | Cisco ASR 1004 and ASR 1006 chassis Note: The Cisco ASR 1002 chassis comes with the Cisco ASR 1000 Series RP1 built into the chassis. Note: Cisco ASR 1001, ASR 1001-X, and ASR 1002-X (part numbers ASR1001, ASR1001-X, ASR1002-X) have an integrated Route Processor built into the chassis that is not upgradable |
| Software compatibility | Cisco IOS XE Operating System, based on Cisco IOS Software Release 12.2SR |
| Software protocols | Refer to Cisco IOS Software 12.2SR protocol support |
| Connectivity | • Console port (RJ-45 connector) • Auxiliary port (RJ-45 connector) • 10/100/1000 Ethernet port (RJ-45 connector) • Two RJ-48 connectors for BITS input clocks |
| Memory options | • Two 1-GB Double Data Rate 2 (DDR2) mini-DIMMs • Two 2-GB DDR2 mini-DIMMs • Upgradable memory from 2-GB to 4-GB DRAM |
| Storage options | • 40-GB HDD (RP1 only) • 1-GB USB Compact Flash memory |
| Performance | • Scalability up to 1,000,000 IPv4 routes or 500,000 IPv6 routes • BGP RR Scalability up to 5,000,000 IPv4 routes or 3,000,000 IPv6 routes |
| Reliability and availability | • 1 + 1 redundancy in dual-route-processor configuration • Support for online insertion and removal (OIR) • Support for NSF and Stateful Switchover (SSO) • Support for ISSU |
| MIBs | • RFC 2737 compliant |
| Network management | • Telnet and Secure Shell (SSH) Protocol (CLI) • Console port (CLI) • Simple Network Management Protocol (SNMP) • RFC 2665 |
| LEDs | • PWR - Power: Green - All power rails within specifications • STAT - Status: Green - IOS booted; Yellow - BootROM loaded; Red - Failure or boot • ACTV - Active: Green - Active RP • STBY - Standby: Yellow - Standby RP • CRIT - Critical: Red - Alarm or during boot • MAJ - Major: Red - Major alarm • MIN - Minor: Amber - Minor alarm • LINK - Ethernet: Solid green - Link no activity; Flash green - Activity; Off - No link • DISK0 - Internal Flash: Flash green - Activity; Off - No activity • DISK1 - External Flash: Flash green - Activity; Off - No activity • DISK2 - Internal HDD: Flash green - Activity • CARRIER - BITS: Off - Out of service; Green - In frame/service; Amber - Fault |
| Physical dimensions (H x W x D) | 0.92 x 16.7 x 14.19 in. (0.02 x 0.428 x 0.36m) |
| Weight | 5.0 lb (2.3 kg) |
| Approvals and compliance | Safety • UL60950-1 and CAN/CSA-C22.2 No. 60950-1-03 • AS/NZS 60950-1 • IEC/EN 60950-1 • 73/23/EEC Emissions • AS/NZ 3548: 1995 (AMD I + II) Class B • EN55022: 1998 Class B • CISPR 22: 1997 • EN55022: 1994 (AMD I + II) • 47 CFR Part 15: 2000 (FCC) Class B • VCCI V-3/01.4 Class 2 • CNS-13438: 1997 Class B • GR1089: 1997 (Rev. 1: 1999) Immunity • EN300386: 2000-TNE EMC • EN50082-1: 1992/1997 • EN50082-2: 1995 Industrial • CISPR24: 1997 • EN55024: 1998 • IEC-1000-4-2/3/4/5/6/11 • EN61000-6-1/2 • ETSI 300 132-2/386-1/386-2 NEBS • GR-1089-CORE • GR-63-CORE ETSI • ETSI 300 386-1 and 2 • ETSI 300 132-2 |
Compare Routers
| Feature | RP1 | RP2 | RP3 |
|---|---|---|---|
| Chassis support | ASR1004 ASR1006 |
ASR1004, ASR1006, ASR1006-X, ASR1009-X, and ASR1013 |
ASR1006-X ASR1009-X ASR1013 |
| Cisco IOS® XE operating system | 32 bit | 64 bit | 64 bit |
| CPU | General-purpose CPU based on 1.5-GHz processor | Dual-core processor, 2.66 GHz | Quad-core processor, 2.2 GHz |
| Memory | 4 GB | 8 GB (default) 16 GB |
8 GB (default) 16 GB 32 GB 64 GB |
| Built-in eUSB/eMMC bootflash | 1 GB (8 GB on ASR 1002) | 2 GB | 8 GB SSD (default) |
| Storage | 40 GB HDD and external USB | 80 GB HDD and external USB | 100 GB SSD (default) 200 GB SSD 400 GB SSD External USB |
