Specs
-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.
What's New for DL360 Gen9
- Intel Xeon E5-2600 v4 Processors with 21% performance gain and up to 22 cores
- 2400MHz DDR4 memory offering up to 23% performance gain and 3.0 TB max capacity with 128GB LRDIMMs
- HPE 25Gb Ethernet Adapters to help improve performance with latency sensitive applications
- Industry-leading NVMe PCIe SFF SSDs up to 2.0 TB for low latency and top performance
- Direct connect up to 16 drives with HPE Smart Array P840ar Controller
- Build a fully functional server with ClearOS that is just right for you at no upfront cost. For more information, check the ClearOS link on the right.
Leveraging Intel’s latest E5-2600 v4 processors with 21% performance gain, plus the latest 2400 MHz HPE DDR4 SmartMemory supporting up to 3 TB and up to 23% performance increase. Manage your DL360 Gen9 Server in any IT environment by automating the most essential server lifecycle management tasks with HPE OneView and HPE Integrated Lights-Out: deploy, update, monitor and maintain with ease.
Other Versions:
- HPE ProLiant DL360 Gen9
- HPE ProLiant DL360 Gen10
- HPE ProLiant DL360 Gen10 Plus
- HPE ProLiant DL360 Gen11 20 EDSFF
- HPE ProLiant DL360 Gen11 8SFF
- HPE ProLiant DL360 Gen11 4LFF
(Click to View)
Ideal for:
- Cloud Servers
- Corporate IT
- Database
- Retail Servers
| Dense and Flexible High-Performance Compute Power
The HPE ProLiant DL360 Gen9 Server has up to 24 HPE DDR4 SmartMemory DIMM slots with up to 3 TB max memory, built-in intelligence to improve performance, reduce downtime and energy costs resulting in up to 23% better throughput performance.
You have a choice of Embedded 4x1GbE, HPE FlexibleLOM, PCIe standup 1GbE to 10/25GbE to 40GbE adapters which provides flexibility of networking bandwidth and fabric so you can adapt and grow to changing business needs.
Achieve greater capacity with flexible drive configuration options with up to ten SFF, four LFF drive along with option to support up to six NVMe PCIe SSDs delivering optimal performance, capacity, and reliability to meet various customer segments and workload requirements at the right economics.
HPE Persistent Memory, the world's first Non-volatile DIMM (NVDIMM) optimized on ProLiant, offering unprecedented levels of performance for databases and analytic workloads
Looking to Customize?
Need assistance with customization? Our sales experts are here to help you.
Start Customizing Today!
Spec Sheet 4
| Technical specifications | HP ProLiant DL360 Gen9 Server |
|---|---|
| Compute | Up to two Intel Xeon E5-2600 v3 series, 4/6/8/10/12/14/16/18 cores, PCIe 3.0, up to three available slot(s) |
| Memory | HP SmartMemory (24) DDR4, up to 2,133 MHz (768 GB max) |
| Storage | Standard HP Dynamic Smart Array B140i Choice of HP Flexible Smart Array or HP Smart Host Bus Adapter Controllers for performance or additional features |
| Flash-backed write cache (FBWC) | 2 GB DDR3-1, 866 MHz, 72-bit wide bus at 14.9 GB/s on P440ar |
| Battery | HP DL/ML/SL 96 W Smart Storage Battery |
| HP SmartDrives | 8 + 2 SFF/4 LFF max, HDD/SSD |
| Networking | 4 x 1GbE embedded + FlexibleLOM slot |
| VGA/serial/USB ports/SD | Front VGA opt, rear VGA standard, and serial opt., 5 USB 3.0 |
| GPU Support | Two single-wide and active to 9.5" in length, up to 150 W each |
| On Premise management | HP OneView and HP iLO Advanced |
| On Cloud management | HP Insight Online with enhanced mobile application |
| On System management | Changes in HP iLO, HP SUM, Intelligent Provisioning and scripting tools; plus the new UEFI and HP RESTful Interface Tool |
| Power and cooling | Up to 94 percent efficient (Platinum Plus) with HP Flexible Slot FF Hot plug fans with full N+1 redundancy, optional high performance fans |
| Industry compliance | ASHRAE A3 and A4, lower idle power |
| Form factor/Chassis depth | ASHRAE A3 |
| Form factor/chassis depth | Rack (1U), 27.5" (SFF), 29.5" (LFF) |
| Serviceability — Easy install rails | Standard |
